● FOUNTAIN PUMP / VFD

SW-60/120/250Series Stainless Steel Centrifugal Pump

Name: SW-60/120/250 Series Stainless Steel Centrifugal Pump
Brand: APP

APP SW-60/120/250 Series Multistage / Centrifugal Pump from Taiwan.

pumpsSW-60/120/250Request quotation

Choose pump configuration

Variant Voltage / Phase Motor Voltage Motor Power Flow / Head Outlet Length Weight Control cabinet Quantity

Add to Project Builder

👁 67

Technical Specifications

Series	SW-60/120/250 Series
Pump Series	SW-60/120/250
Pump Type	Multistage / Centrifugal Pump
Flow / head
Outlet
Water Temperature	0~70℃ / 32~158℉
pH Range	6~8
Pump construction	IP55
Material	Stainless steel wetted parts

Project Integration

SW-60/120/250 Series Stainless Steel Centrifugal Pump is suitable for auxiliary applications such as pump control, condensate drainage, cooling, light chemical handling or other special-purpose systems depending on the model. Selection should check liquid type, temperature, pressure, wetted material and duty conditions.

Select the model by project flow and working head
Check power, voltage/frequency, outlet size, material and installation dimensions
Add to BOM/RFQ together with accessories, piping, valves, electrical cabinet or VFD when required
Support configuration comparison and quotation by actual project quantity

PUMP MODELS

Pump Selection Table by Model

Model	Motor Power (HP/kW/W)	Voltage / Phase	Outlet (inch/mm)	Max Flow (LPM)	Max Head (m)	Pass Solid (mm)	Dimension (L×W×H mm)	Weight (kg)	Accessories
SW-60 SW-60	1/2 HP / 0.4 kW	220V / 1P	25 mm / 1"	120 LPM	17 m	—	315	11 kg	—
SW-120 SW-120	1.25 HP / 1.0 kW	220V / 1P \| 380V / 3P	25 mm / 1"	140 LPM	28 m	—	360	15.5 kg	—
SW-120(T) SW-120(T)	1.25 HP / 1.0 kW	220V / 1P \| 380V / 3P	25 mm / 1"	140 LPM	28 m	—	Not specified in catalogue	—	—
SW-120S SW-120S	1.25 HP / 1.0 kW	220V / 1P \| 380V / 3P	25 mm / 1"	140 LPM	28 m	—	360	15.5 kg	—
SW-120ST SW-120ST	1.25 HP / 1.0 kW	220V / 1P \| 380V / 3P	25 mm / 1"	140 LPM	28 m	—	Not specified in catalogue	—	—
SW-250 SW-250	2.5 HP / 1.85 kW	220V / 1P \| 380V / 3P	32 mm / 1-1/4"	300 LPM	30 m	—	366	20 kg	—
SW-250S SW-250S	2.5 HP / 1.85 kW	220V / 1P \| 380V / 3P	32 mm / 1-1/4"	300 LPM	30 m	—	366	20 kg	—
SW-250S(ST) SW-250S(ST)	2.5 HP / 1.85 kW	220V / 1P \| 380V / 3P	32 mm / 1-1/4"	300 LPM	30 m	—	Not specified in catalogue	—	—
