RVSeries Dirty Water Pumps
APP RV Series Dirty Water Pump from Taiwan.
Technical Specifications
| source | APP catalogue |
|---|---|
| section | Domestic |
| series | RV |
| family | Dirty Water Pump |
| catalogue_page | Domestic 43-44 |
| features | Small dirty-water pump with PIN cable and low residual water design. |
| Series | RV Series |
| Pump Series | RV |
| Pump Type | Dirty Water Pump |
| Max Diving Depth | 8 m |
| Water Temperature | 0~40℃ / 32~104℉ |
| pH Range | 6~8 |
| Pump construction | IP68 |
| Variant Dimensions | 154 x 143 x 345 mm |
| Pump length / size | 154 x 143 x 345 mm |
| Variant Max Flow | 130 LPM / 160 LPM |
| Variant Max Head | 6.5 m / 8 m |
| Variant Pass Solid | 18 mm |
| Variant Weight | 3.9 kg / 5.9 kg |
Project Integration
RV Series Dirty Water Pumps is suitable for drainage, dirty water, sewage, sump pits, basements, construction sites or solids-handling applications depending on the pump family. Selection should check allowable solid size, flow, head, outlet size, protection class and real operating conditions.
- Select the model by project flow and working head
- Check power, voltage/frequency, outlet size, material and installation dimensions
- Add to BOM/RFQ together with accessories, piping, valves, electrical cabinet or VFD when required
- Support configuration comparison and quotation by actual project quantity
Pump Selection Table by Model
Applications & Key Features
Overview
APP RV Series is a dirty water pump for Water exclusion; pool drainage; horticulture; basement; elevator pit applications.
Applications
Water exclusion; pool drainage; horticulture; basement; elevator pit
Key features
Small dirty-water pump with PIN cable and low residual water design.
