DCSeries Bilge Pumps

Name: DC Series Bilge Pumps
Brand: APP

APP DC Series Manual / Bilge Pump from Taiwan.

pumpsDCRequest quotation

Choose pump configuration

Variant Voltage / Phase Motor Voltage Motor Power Flow / Head Outlet Length Weight Control cabinet Quantity

Add to Project Builder

👁 61

Technical Specifications

source	APP catalogue
section	Auxiliary
series	DC
family	Manual / Bilge Pump
catalogue_page	Auxiliary 01-02
features	DC bilge pumps for 12/24V drainage applications.
Series	DC Series
Pump Series	DC
Pump Type	Manual / Bilge Pump
Water Temperature	0~40℃ / 32~104℉
pH Range	6~8
Variant Dimensions	245 x 188 x 420 mm / 280 x 195 x 420 mm / 285 x 223 x 550 mm
Pump length / size	245 x 188 x 420 mm / 280 x 195 x 420 mm / 285 x 223 x 550 mm
Variant Max Flow	115 LPM / 145 LPM / 190 LPM
Variant Max Head	4.6 m / 5.2 m / 5.5 m
Variant Pass Solid	3 mm
Variant Weight	0.75 kg / 2.3 kg / 2.6 kg

Project Integration

DC Series Bilge Pumps is suitable for landscape ponds, fish ponds, garden waterfalls, water circulation and small-to-medium fountain applications. Model selection should be based on required flow, working head, outlet size and actual installation conditions.

Select the model by project flow and working head
Check power, voltage/frequency, outlet size, material and installation dimensions
Add to BOM/RFQ together with accessories, piping, valves, electrical cabinet or VFD when required
Support configuration comparison and quotation by actual project quantity

PUMP MODELS

Pump Selection Table by Model

Model	Motor Power (HP/kW/W)	Voltage / Phase	Outlet (inch/mm)	Max Flow (LPM)	Max Head (m)	Pass Solid (mm)	Dimension (L×W×H mm)	Weight (kg)	Accessories
DC-1824 DC-1824	5A	24VDC	25 mm / 1"	115 LPM	4.6 m	3 mm	245	0.75 kg	—
DC-2324 DC-2324	5.5A	24VDC	25 mm / 1"	145 LPM	5.2 m	3 mm	280	2.3 kg	—
DC-3024 DC-3024	7A	24VDC	32 mm / 1-1/4"	190 LPM	5.5 m	3 mm	285	2.6 kg	—
DC-1812 DC-1812	8A	12VDC	25 mm / 1"	115 LPM	4.6 m	3 mm	245	0.75 kg	—
DC-2312 DC-2312	11A	12VDC	25 mm / 1"	145 LPM	5.2 m	3 mm	280	2.3 kg	—
