BASSeries Dirty Water Pumps

Name: BAS Series Dirty Water Pumps
Brand: APP

APP BAS Series Dirty Water Pump from Taiwan.

pumpsBASRequest quotation

Choose pump configuration

Variant Voltage / Phase Motor Voltage Motor Power Flow / Head Outlet Length Weight Control cabinet Quantity

Add to Project Builder

👁 77

Technical Specifications

source	APP catalogue
section	Domestic
series	BAS
family	Dirty Water Pump
catalogue_page	Domestic 05-06
features	Power cable insulation; suspended impeller; one-piece stainless motor casing.
Series	BAS Series
Pump Series	BAS
Pump Type	Dirty Water Pump
Max Diving Depth	8 m
Water Temperature	0~40℃ / 32~104℉
pH Range	6~8
Pump construction	IP68
Material	Stainless motor casing
Variant Dimensions	190 x 130 x 280 mm / 200 x 135 x 285 mm / 236 x 145 x 352 mm / 276 x 165 x 425 mm
Pump length / size	190 x 130 x 280 mm / 200 x 135 x 285 mm / 236 x 145 x 352 mm / 276 x 165 x 425 mm
Variant Max Flow	90 LPM / 140 LPM / 200 LPM / 270 LPM / 300 LPM
Variant Max Head	6 m / 7 m / 8 m / 10 m / 11 m
Variant Pass Solid	7 mm / 9 mm / 12 mm / 15 mm
Variant Weight	5 kg / 6 kg / 6.5 kg / 10 kg / 12 kg

Project Integration

BAS Series Dirty Water Pumps is suitable for drainage, dirty water, sewage, sump pits, basements, construction sites or solids-handling applications depending on the pump family. Selection should check allowable solid size, flow, head, outlet size, protection class and real operating conditions.

Select the model by project flow and working head
Check power, voltage/frequency, outlet size, material and installation dimensions
Add to BOM/RFQ together with accessories, piping, valves, electrical cabinet or VFD when required
Support configuration comparison and quotation by actual project quantity

PUMP MODELS

Pump Selection Table by Model

Model	Motor Power (HP/kW/W)	Voltage / Phase	Outlet (inch/mm)	Max Flow (LPM)	Max Head (m)	Pass Solid (mm)	Dimension (L×W×H mm)	Weight (kg)	Accessories
BAS-100 BAS-100	1/6 HP / 100 W	—	25 mm / 1"	90 LPM	6 m	7 mm	190	5 kg	—
BAS-200 BAS-200	1/5 HP / 150 W	220V / 1P	32 mm / 1-1/4"	140 LPM	7 m	7 mm	190	6 kg	—
BAS-300 BAS-300	1/3 HP / 250 W	220V / 1P	40 mm / 1-1/2"	200 LPM	8 m	9 mm	200	6.5 kg	—
BAS-400 BAS-400	1/2 HP / 400 W	—	50 mm / 2"	270 LPM	10 m	12 mm	236	10 kg	—
BAS-600 BAS-600	3/4 HP / 550 W	—	50 mm / 2"	300 LPM	11 m	15 mm	276	12 kg	—
