RXLGAluminum Housing Braking Resistor

Aluminum-housed braking resistor series from 60 W to 10,000 W for VFD, servo and power-electronic braking circuits.

electrical-equipment-cablesRXLGRequest quotation

Choose braking resistor model

ModelRated PowerResistanceToleranceDimensions L×B×HMounting holesLead length L2Wire cross-sectionReference weightQuantity

Add to Project BOM

👁 100

Technical Specifications

Series	RXLG
Installation Type	Panel / heatsink mounting
Housing Material	Aluminum alloy housing
Operating Temperature	-55°C to 275°C derating curve; 100% rated power up to 70°C

Project Integration

Dissipates regenerative energy during deceleration or stopping of VFD-controlled pumps and helps prevent DC-bus overvoltage. Select wattage, resistance and duty cycle according to the VFD manual.

BRAKING RESISTOR MODELS

RXLG technical specifications by model

Total models: 27

Model	Rated Power	Resistance	Tolerance	Dimensions L×B×H	Mounting holes	Lead length L2	Wire cross-section	Reference weight
RXLG-60W RXLG-60W	60W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø5.5 mm / L3 85 mm	300 mm	1.5 mm²	0.16 kg
RXLG-80W RXLG-80W	80W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø5.5 mm / L3 95 mm	300 mm	1.5 mm²	0.2 kg
RXLG-100W RXLG-100W	100W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø5.5 mm / L3 100 mm	300 mm	1.5 mm²	0.24 kg
RXLG-120W RXLG-120W	120W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø5.5 mm / L3 150 mm	300 mm	1.5 mm²	0.3 kg
RXLG-150W RXLG-150W	150W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø5.5 mm / L3 170 mm	300 mm	1.5 mm²	—
RXLG-200W RXLG-200W	200W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø5.5 mm / L3 200 mm	300 mm	1.5 mm²	—
RXLG-100WL RXLG-100WL	100W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø5.5 mm / L3 85 mm	300 mm	1.5 mm²	—
RXLG-200WL RXLG-200WL	200W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø5.5 mm / L3 150 mm	300 mm	1.5 mm²	—
RXLG-300W RXLG-300W	300W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø5.5 mm / L3 200 mm	300 mm	1.5 mm²	—
RXLG-400W RXLG-400W	400W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø5.5 mm / L3 250 mm	300 mm	1.5 mm²	—
RXLG-500W RXLG-500W	500W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø5.5 mm / L3 270 mm	300 mm	1.5 mm²	—
RXLG-600W RXLG-600W	600W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø5.5 mm / L3 285 mm	300 mm	1.5 mm²	—
RXLG-800W RXLG-800W	800W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø5.5 mm / L3 315 mm	300 mm	1.5 mm²	—
RXLG-1000W RXLG-1000W	1000W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø5.5 mm / L3 370 mm	300 mm	1.5 mm²	—
RXLG-800WL RXLG-800WL	800W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø6.5 mm / L3 195 mm	300 mm	2.5 mm²	—
RXLG-1000WL RXLG-1000WL	1000W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø6.5 mm / L3 285 mm	300 mm	2.5 mm²	—
RXLG-1200W RXLG-1200W	1200W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø6.5 mm / L3 335 mm	300 mm	2.5 mm²	—
RXLG-1500W RXLG-1500W	1500W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø6.5 mm / L3 385 mm	300 mm	2.5 mm²	—
RXLG-2000W RXLG-2000W	2000W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø6.5 mm / L3 435 mm	300 mm	2.5 mm²	—
RXLG-2500W RXLG-2500W	2500W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø6.5 mm / L3 470 mm	300 mm	2.5 mm²	—
RXLG-3000W RXLG-3000W	3000W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø6.5 mm / L3 535 mm	300 mm	2.5 mm²	—
RXLG-4000W RXLG-4000W	4000W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø6.5 mm / L3 635 mm	300 mm	2.5 mm²	—
RXLG-4500W RXLG-4500W	4500W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø6.5 mm / L3 685 mm	300 mm	2.5 mm²	—
RXLG-5000W RXLG-5000W	5000W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø6.5 mm / L3 735 mm	300 mm	2.5 mm²	—
RXLG-6000W RXLG-6000W	6000W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø6.5 mm / L3 835 mm	300 mm	2.5 mm²	—
RXLG-8000W RXLG-8000W	8000W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø6.5 mm / L3 885 mm	300 mm	2.5 mm²	—
RXLG-10000W RXLG-10000W	10000W	Project / VFD specific	F ±1%; G ±2%; J ±5%	See child models	Ø6.5 mm / L3 985 mm	300 mm	2.5 mm²	—
