Thông số kỹ thuật

Dòng sản phẩm	LHS Horizontal Submersible Pumps
Kiểu lắp đặt	Horizontal submersible / Bơm chìm lắp ngang
Kết cấu bơm	IP68
Vật liệu vỏ đèn	Grey iron pump casing

Tích hợp dự án

SmartVision có thể cấu hình model này cùng bơm, điều khiển đèn, DMX/ArtNet, vận hành PWA và bóc tách BOM theo yêu cầu dự án.

DANH SÁCH MODEL BƠM

Bảng chọn bơm theo từng model

Model	Lưu lượng / cột áp	Công suất motor	Điện áp	Cửa xả	Chiều dài	Trọng lượng
LHS-150B LHS-150B	Refer to pump curve / parameter table	0.37 kW / 0.5 HP	230 V (-10% / +10%)	Inlet DN25; Outlet DN25	734 mm	158 kg
LHS-150BH LHS-150BH	Refer to pump curve / parameter table	0.37 kW / 0.5 HP	230 V (-10% / +10%)	Inlet DN25; Outlet DN25	734 mm	158 kg
LHS-51 LHS-51	Refer to pump curve / parameter table	0.75 kW / 1 HP	415 V (-15% / +6%)	Inlet DN25; Outlet DN25	734 mm	158 kg
LHS-52 LHS-52	Refer to pump curve / parameter table	0.75 kW / 1 HP	415 V (-15% / +6%)	Inlet DN40; Outlet DN40	734 mm	158 kg
LHS-53 LHS-53	Refer to pump curve / parameter table	0.75 kW / 1 HP	415 V (-15% / +6%)	Inlet DN50; Outlet DN40	734 mm	158 kg
LHS-54 LHS-54	Refer to pump curve / parameter table	0.75 kW / 1 HP	415 V (-15% / +6%)	Inlet DN50; Outlet DN50	734 mm	158 kg
LHS-151 LHS-151	Refer to pump curve / parameter table	0.75 kW / 1 HP	230 V (-10% / +10%)	Inlet DN25; Outlet DN25	734 mm	158 kg
LHS-152 LHS-152	Refer to pump curve / parameter table	0.75 kW / 1 HP	230 V (-10% / +10%)	Inlet DN40; Outlet DN40	734 mm	158 kg
LHS-55 LHS-55	Refer to pump curve / parameter table	1.1 kW / 1.5 HP	415 V (-15% / +6%)	Inlet DN40; Outlet DN40	734 mm	158 kg
LHS-56 LHS-56	Refer to pump curve / parameter table	1.1 kW / 1.5 HP	415 V (-15% / +6%)	Inlet DN50; Outlet DN40	734 mm	158 kg
LHS-57 LHS-57	Refer to pump curve / parameter table	1.1 kW / 1.5 HP	415 V (-15% / +6%)	Inlet DN50; Outlet DN50	734 mm	158 kg
LHS-155 LHS-155	Refer to pump curve / parameter table	1.1 kW / 1.5 HP	230 V (-10% / +10%)	Inlet DN40; Outlet DN40	734 mm	158 kg
LHS-156 LHS-156	Refer to pump curve / parameter table	1.1 kW / 1.5 HP	230 V (-10% / +10%)	Inlet DN50; Outlet DN40	734 mm	158 kg
LHS-157 LHS-157	Refer to pump curve / parameter table	1.1 kW / 1.5 HP	230 V (-10% / +10%)	Inlet DN50; Outlet DN50	734 mm	158 kg
LHS-58 LHS-58	Refer to pump curve / parameter table	1.5 kW / 2 HP	415 V (-15% / +6%)	Inlet DN40; Outlet DN40	734 mm	158 kg
LHS-59 LHS-59	Refer to pump curve / parameter table	1.5 kW / 2 HP	415 V (-15% / +6%)	Inlet DN50; Outlet DN40	734 mm	158 kg
LHS-60 LHS-60	Refer to pump curve / parameter table	1.5 kW / 2 HP	415 V (-15% / +6%)	Inlet DN50; Outlet DN50	734 mm	158 kg
LHS-61 LHS-61	Refer to pump curve / parameter table	1.5 kW / 2 HP	415 V (-15% / +6%)	Inlet DN65; Outlet DN50	734 mm	158 kg
LHS-64 LHS-64	Refer to pump curve / parameter table	1.5 kW / 2 HP	415 V (-15% / +6%)	Inlet DN80; Outlet DN80	734 mm	158 kg
LHS-158 LHS-158	Refer to pump curve / parameter table	1.5 kW / 2 HP	230 V (-10% / +10%)	Inlet DN40; Outlet DN40	734 mm	158 kg
LHS-159 LHS-159	Refer to pump curve / parameter table	1.5 kW / 2 HP	230 V (-10% / +10%)	Inlet DN50; Outlet DN40	734 mm	158 kg
LHS-160 LHS-160	Refer to pump curve / parameter table	1.5 kW / 2 HP	230 V (-10% / +10%)	Inlet DN50; Outlet DN50	734 mm	158 kg
LHS-1A LHS-1A	Refer to pump curve / parameter table	2.2 kW / 3 HP	415 V (-15% / +6%)	Inlet DN50; Outlet DN38	734 mm	158 kg
LHS-2 LHS-2	Refer to pump curve / parameter table	2.2 kW / 3 HP	415 V (-15% / +6%)	Inlet DN65; Outlet DN65	734 mm	158 kg
LHS-2AH LHS-2AH	Refer to pump curve / parameter table	2.2 kW / 3 HP	415 V (-15% / +6%)	Inlet DN65; Outlet DN50	734 mm	158 kg
LHS-3A LHS-3A	Refer to pump curve / parameter table	2.2 kW / 3 HP	415 V (-15% / +6%)	Inlet DN80; Outlet DN65	734 mm	158 kg
LHS-4A LHS-4A	Refer to pump curve / parameter table	3.7 kW / 5 HP	415 V (-15% / +6%)	Inlet DN50; Outlet DN38	734 mm	158 kg
LHS-5 LHS-5	Refer to pump curve / parameter table	3.7 kW / 5 HP	415 V (-15% / +6%)	Inlet DN65; Outlet DN65	734 mm	158 kg
LHS-5A LHS-5A	Refer to pump curve / parameter table	3.7 kW / 5 HP	415 V (-15% / +6%)	Inlet DN65; Outlet DN50	734 mm	158 kg
LHS-5AH LHS-5AH	Refer to pump curve / parameter table	3.7 kW / 5 HP	415 V (-15% / +6%)	Inlet DN65; Outlet DN50	734 mm	158 kg
LHS-5B LHS-5B	Refer to pump curve / parameter table	3.7 kW / 5 HP	415 V (-15% / +6%)	Inlet DN65; Outlet DN50	734 mm	158 kg
LHS-5H LHS-5H	Refer to pump curve / parameter table	3.7 kW / 5 HP	415 V (-15% / +6%)	Inlet DN65; Outlet DN65	734 mm	158 kg
LHS-6 LHS-6	Refer to pump curve / parameter table	3.7 kW / 5 HP	415 V (-15% / +6%)	Inlet DN80; Outlet DN80	734 mm	158 kg
LHS-6A LHS-6A	Refer to pump curve / parameter table	3.7 kW / 5 HP	415 V (-15% / +6%)	Inlet DN80; Outlet DN65	734 mm	158 kg
LHS-16 LHS-16	Refer to pump curve / parameter table	3.7 kW / 5 HP	415 V (-15% / +6%)	Inlet DN100; Outlet DN100	734 mm	158 kg
LHS-9 LHS-9	Refer to pump curve / parameter table	5.5 kW / 7.5 HP	415 V (-15% / +6%)	Inlet DN65; Outlet DN65	734 mm	158 kg
LHS-9A LHS-9A	Refer to pump curve / parameter table	5.5 kW / 7.5 HP	415 V (-15% / +6%)	Inlet DN65; Outlet DN50	734 mm	158 kg
LHS-9AH LHS-9AH	Refer to pump curve / parameter table	5.5 kW / 7.5 HP	415 V (-15% / +6%)	Inlet DN65; Outlet DN50	734 mm	158 kg
LHS-9B LHS-9B	Refer to pump curve / parameter table	5.5 kW / 7.5 HP	415 V (-15% / +6%)	Inlet DN65; Outlet DN50	734 mm	158 kg
LHS-10 LHS-10	Refer to pump curve / parameter table	5.5 kW / 7.5 HP	415 V (-15% / +6%)	Inlet DN80; Outlet DN80	734 mm	158 kg
LHS-17 LHS-17	Refer to pump curve / parameter table	5.5 kW / 7.5 HP	415 V (-15% / +6%)	Inlet DN100; Outlet DN100	734 mm	158 kg
LHS-19 LHS-19	Refer to pump curve / parameter table	5.5 kW / 7.5 HP	415 V (-15% / +6%)	Inlet DN125; Outlet DN125	734 mm	158 kg
LHS-13 LHS-13	15–54 m³/h	7.5 kW / 10 HP	400 V	Inlet 2-1/2"; Outlet 2-1/2"	734 mm	158 kg
LHS-13AH LHS-13AH	15–60 m³/h	7.5 kW / 10 HP	400 V	Inlet 2-1/2"; Outlet 2"	734 mm	150 kg
LHS-14 LHS-14	30–90 m³/h	7.5 kW / 10 HP	400 V	Inlet 3"; Outlet 3"	743 mm	129 kg
LHS-15 LHS-15	60–105 m³/h	7.5 kW / 10 HP	400 V	Inlet 4"; Outlet 4"	763 mm	142 kg
LHS-20 LHS-20	60–192 m³/h	7.5 kW / 10 HP	400 V	Inlet 5"; Outlet 5"	794 mm	173 kg
LHS-18 LHS-18	Refer to pump curve / parameter table	7.5 kW / 10 HP	415 V (-15% / +6%)	Inlet DN100; Outlet DN100	734 mm	158 kg
LHS-21 LHS-21	15–54 m³/h	9.3 kW / 12.5 HP	400 V	Inlet 2-1/2"; Outlet 2-1/2"	783 mm	173 kg
LHS-25 LHS-25	60–105 m³/h	9.3 kW / 12.5 HP	400 V	Inlet 4"; Outlet 4"	813 mm	168 kg
LHS-26 LHS-26	60–192 m³/h	9.3 kW / 12.5 HP	400 V	Inlet 5"; Outlet 5"	844 mm	177 kg
LHS-21A LHS-21A	Refer to pump curve / parameter table	9.3 kW / 12.5 HP	415 V (-15% / +6%)	Inlet DN65; Outlet DN65	734 mm	158 kg
LHS-21H LHS-21H	Refer to pump curve / parameter table	9.3 kW / 12.5 HP	415 V (-15% / +6%)	Inlet DN50; Outlet DN50	734 mm	158 kg
LHS-21L LHS-21L	Refer to pump curve / parameter table	9.3 kW / 12.5 HP	415 V (-15% / +6%)	Inlet DN50; Outlet DN50	734 mm	158 kg
LHS-23 LHS-23	Refer to pump curve / parameter table	9.3 kW / 12.5 HP	415 V (-15% / +6%)	Inlet DN80; Outlet DN80	734 mm	158 kg
LHS-24 LHS-24	Refer to pump curve / parameter table	9.3 kW / 12.5 HP	415 V (-15% / +6%)	Inlet DN100; Outlet DN80	734 mm	158 kg
LHS-27 LHS-27	15–60 m³/h	11 kW / 15 HP	400 V	Inlet 2-1/2"; Outlet 2"	787 mm	190 kg
LHS-28 LHS-28	15–60 m³/h	11 kW / 15 HP	400 V	Inlet 2-1/2"; Outlet 2-1/2"	798 mm	196 kg
LHS-29 LHS-29	30–96 m³/h	11 kW / 15 HP	400 V	Inlet 3"; Outlet 3"	808 mm	200 kg
LHS-31 LHS-31	60–120 m³/h	11 kW / 15 HP	400 V	Inlet 4"; Outlet 4"	833 mm	209 kg
LHS-27H LHS-27H	Refer to pump curve / parameter table	11 kW / 15 HP	415 V (-15% / +6%)	Inlet DN50; Outlet DN50	734 mm	158 kg
LHS-27L LHS-27L	Refer to pump curve / parameter table	11 kW / 15 HP	415 V (-15% / +6%)	Inlet DN50; Outlet DN50	734 mm	158 kg
LHS-30 LHS-30	Refer to pump curve / parameter table	11 kW / 15 HP	415 V (-15% / +6%)	Inlet DN100; Outlet DN80	734 mm	158 kg
LHS-32 LHS-32	Refer to pump curve / parameter table	11 kW / 15 HP	415 V (-15% / +6%)	Inlet DN125; Outlet DN125	734 mm	158 kg
LHS-33 LHS-33	15–60 m³/h	15 kW / 20 HP	400 V	Inlet 2-1/2"; Outlet 2-1/2"	797 mm	218 kg
LHS-34 LHS-34	30–96 m³/h	15 kW / 20 HP	400 V	Inlet 3"; Outlet 3"	808 mm	222 kg
LHS-35 LHS-35	60–135 m³/h	15 kW / 20 HP	400 V	Inlet 4"; Outlet 4"	833 mm	236 kg
LHS-36 LHS-36	60–192 m³/h	15.0 kW / 20 HP	400 V	Inlet 5"; Outlet 5"	855 mm	222 kg
LHS-34A LHS-34A	Refer to pump curve / parameter table	15 kW / 20 HP	415 V (-15% / +6%)	Inlet DN80; Outlet DN65	734 mm	158 kg
LHS-38 LHS-38	60–135 m³/h	18.5 kW / 25 HP	400 V	Inlet 4"; Outlet 4"	833 mm	234 kg
LHS-39 LHS-39	60–192 m³/h	18.5 kW / 25 HP	400 V	Inlet 5"; Outlet 5"	855 mm	220 kg
LHS-37 LHS-37	Refer to pump curve / parameter table	18.5 kW / 25 HP	415 V (-15% / +6%)	Inlet DN80; Outlet DN80	734 mm	158 kg
LHS-40 LHS-40	30–96 m³/h	22 kW / 30 HP	400 V	Inlet 3"; Outlet 3"	807 mm	223 kg
LHS-41 LHS-41	60–150 m³/h	22 kW / 30 HP	400 V	Inlet 4"; Outlet 4"	833 mm	231 kg
LHS-42 LHS-42	60–192 m³/h	22.0 kW / 30 HP	400 V	Inlet 5"; Outlet 5"	855 mm	232 kg
LHS-43 LHS-43	Refer to pump curve / parameter table	22 kW / 30 HP	415 V (-15% / +6%)	Inlet DN150; Outlet DN150	734 mm	158 kg
